Bit #14 = 1: The Laser Control Signals are enabled (enable_laser).
= 0: The Laser Control Signals are disabled (disable_laser).
Bit #15 = 1: If previously activated by eth_configure_link_loss:
An Ethernet Link Loss has been detected since the last call of
get_startstop_info.
Bit #16
…
Bit #31
The error bits. Get set when an error occurs during data transmission from the
scan system:
Bit #16…Bit #23 for the first scan head connector,
Bit #24…Bit #31 for the second scan head connector.
Bit #16, Bit #24: Incorrect number of frames within a data block.
Bit #17, Bit #25: Incorrect pulse length of signal received from
scan system, maybe no scan system is connected.
Bit #18, Bit #26: Preamble sequence incorrect.
Bit #19, Bit #27: Bit count within a subframe incorrect.
Bit #20, Bit #28: Parity error when reading data received from
scan system.
Bit #21, Bit #29: The present data is invalid (old).
Bit #22, Bit #30: Reserved.
Bit #23, Bit #31: Reserved.
Comments • After get_startstop_info has been executed, reset are:
– The info bits Bit #0…Bit #3, Bit #15
– The error bits Bit #5, Bit #16…Bit #31
• See also Section ”External Stop”, page 289 and Section ”External Start”, page 290.
RTC4RTC6 Unchanged functionality for info bits that are also used on the RTC4.
RTC5RTC6 Unchanged functionality for info bits that are also used on the RTC5.
Version info Available as of DLL 600, OUT 600, RBF 600.
Last change DLL 622, OUT 622: Bit #15.
References get_counts, get_status, set_control_mode
Ctrl Command get_startstop_info
