Comments
(cont’d)
• If Pulses = 0, then laser_on_pulses_list has no effect (the LASERON signal is not
switched on). Then laser_on_pulses_list becomes a short list command.
• The LASERON signal must first be defined and enabled by set_laser_control or
enable_laser before it can be switched on with laser_on_pulses_list, see Chapter 7.4
”Laser Control”, page 184.
• While tlaser_on_pulses_list is executed, the set position of the scanners is not
changed. The next list command is executed when the programmed time interval
Period has passed.
• The Wobbel Mode, see Chapter 8.4 ”Wobbel Mode”, page 232, is retained but
ignored.
• Any softstarts that were defined are not executed.
RTC4RTC6 New command.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References laser_on_list, para_laser_on_pulses_list
Variable
List Command
laser_on_pulses_list
