RTC6 boards
Doc. Rev. 1.0.21 en-US
10 RTC6 Commands
497
RTC4RTC6 Except its basic function and the parameters
Name
and
No
, the functionality of
load_correction_file has substantially changed:
• load_correction_file now uses the new parameter
Dim
. This allows, for instance,
storage of 3D correction files as 2D correction tables and storage of 2D correction files
as 3D correction tables.
• Now, up to 8 3D correction tables can be stored in RTC6 memory (in the 3D-enabled
version). However, two 3D correction tables can not be simultaneously assigned to the
scan head connector (see select_cor_table).
• The parameters
k
,
Phi
and
Offset
no longer exist. Therefore, table transformations
(scaling, rotation, translation) are no longer possible during loading of the
correction file. Such coordinate transformations can now be specified by set_scale,
set_angle and set_offset in addition to set_matrix.
• select_cor_table is automatically called, see comments above and Section ”Notes”,
page 176.
• load_correction_file does not return to the user program until the correction motion
has been completed (see comments above).
RTC5RTC6 Changed functionality.
• load_correction_file lets you load 8 correction tables simultaneously into the RTC6
memory.
• Overlaps no longer exist between memory areas used elsewhere.
Version info Available as of DLL 600, OUT 600, RBF 600.
References —
