10 RTC6 Commands
643
innovators for industry
Comments
(cont’d)
• The following command calls are executed in the same way:
– set_fly_2_axes ( 1 , 1 , ScaleX, 2 , 2 , ScaleY ) = set_fly_2d( ScaleX, ScaleY )
– set_fly_2_axes ( 1 , 1 , ScaleX, 2 , 2 , ScaleY ) =
{
set_fly_1_axis( 1, 1, ScaleX );
set_fly_1_axis( 2, 2, ScaleY ));
}
Encoder resets occur:
• With a single set_fly_2_axes call in the same 10 µs clock cycle
• With two set_fly_1_axis calls in two different 10 µs clock cycles
– set_fly_2_axes( 1, 11, Scale , 2, 15, Scale ) corresponds to
set_mcbsp_in_list( 3, Scale )
RTC4RTC6 New command.
RTC5RTC6 New command.
Version info Available as of DLL 617, OUT 617, RBF 623.
References set_fly_1_axis, set_fly_3_axes
Normal List
Command
set_fly_2_axes
