10 RTC6 Commands
645
innovators for industry
Comments
(cont’d)
• If no correction table for 2D encoder compensation has yet been loaded onto the
board (see load_fly_2d_table), then the encoder values are used without correction.
• You can also use activate_fly_2d/activate_fly_2d_encoder to switch on set_fly_2d
Processing-on-the-fly correction.
RTC4RTC6 New command.
In RTC4 Compatibility Mode, the RTC6 multiplies the specified values for ScaleX and ScaleY
by 16. The allowed value range decreases accordingly.
RTC5RTC6 Unchanged functionality.
Version info Available as of DLL 600, OUT 600, RBF 600.
References init_fly_2d, load_fly_2d_table, get_fly_2d_offset, activate_fly_2d, activate_fly_xy
Normal List
Command
set_fly_2d
