RM0351 USB on-the-go full-speed (OTG_FS)
1774
OTG_DIEPEMPMSK 0x834
OTG device IN endpoint FIFO empty interrupt mask register
(OTG_DIEPEMPMSK) on page 1700
OTG_DIEPCTL0 0x900
OTG device control IN endpoint 0 control register (OTG_DIEPCTL0) on
page 1700
OTG_DIEPCTLx
0x920
0x940
...
0x9A0
OTG device endpoint-x control register (OTG_DIEPCTLx) (x = 1..5 ,
where x = Endpoint_number) on page 1702
OTG_DIEPINTx
0x908
0x928
....
0x9A8
OTG device endpoint-x interrupt register (OTG_DIEPINTx) (x = 0..5,
where x = Endpoint_number) on page 1708
OTG_DIEPTSIZ0 0x910
OTG device IN endpoint 0 transfer size register (OTG_DIEPTSIZ0) on
page 1710
OTG_DTXFSTSx
0x918
0x938
....
0x9B8
OTG device IN endpoint transmit FIFO status register
(OTG_DTXFSTSx) (x = 0..5, where x = Endpoint_number) on
page 1713
OTG_DIEPTSIZx
0x930
0x950
...
0x9B0
OTG device IN endpoint-x transfer size register (OTG_DIEPTSIZx)
(x = 1..5, where x= Endpoint_number) on page 1712
OTG_DOEPCTL0 0xB00
OTG device control OUT endpoint 0 control register
(OTG_DOEPCTL0) on page 1704
OTG_DOEPCTLx
0xB20
0xB40
...
0xBA0
OTG device endpoint-x control register (OTG_DOEPCTLx) (x = 1..5,
where x = Endpoint_number) on page 1706
OTG_DOEPINTx
0xB08
0xB28
...
0xBA8
OTG device endpoint-x interrupt register (OTG_DOEPINTx) (x = 0..5,
where x = Endpoint_number) on page 1709
OTG_DOEPTSIZ0 0xB10
OTG device OUT endpoint 0 transfer size register (OTG_DOEPTSIZ0)
on page 1711
OTG_DOEPTSIZx
0xB30
0xB50
...
0xBB0
OTG device OUT endpoint-x transfer size register (OTG_DOEPTSIZx)
(x = 1..5, where x = Endpoint_number) on page 1713
Table 304. Device-mode control and status registers (continued)
Acronym
Offset
address
Register name
