DocID024597 Rev 5 241/1830
RM0351 Reset and clock control (RCC)
278
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
LPTIM1
RST
OPAMP
RST
DAC1
RST
PWR
RST
Res.
CAN2R
ST
CAN1
RST
CRSRS
T
I2C3R
ST
I2C2
RST
I2C1
RST
UART5
RST
UART4
RST
USART3
RST
USART2
RST
Res.
rw rw rw rw rw rw rw rw rw rw rw rw rw
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
SPI3
RST
SPI2
RST
Res. Res. Res. Res.
LCD
RST
Res. Res. Res.
TIM7
RST
TIM6
RST
TIM5
RST
TIM4
RST
TIM3
RST
TIM2
RST
rw rw rw rw rw rw rw rw rw
Bit 31 LPTIM1RST: Low Power Timer 1 reset
Set and cleared by software.
0: No effect
1: Reset LPTIM1
Bit 30 OPAMPRST: OPAMP interface reset
Set and cleared by software.
0: No effect
1: Reset OPAMP interface
Bit 29 DAC1RST: DAC1 interface reset
Set and cleared by software.
0: No effect
1: Reset DAC1 interface
Bit 28 PWRRST: Power interface reset
Set and cleared by software.
0: No effect
1: Reset PWR
Bit 27 Reserved, must be kept at reset value.
Bit 26 CAN2RST: CAN2 reset (This bit is reserved for STM32L475xx/476xx/486xx devices)
Set and cleared by software
0: No effect
1: Reset CAN2
Bit 25 CAN1RST: CAN1 reset
Set and reset by software.
0: No effect
1: Reset the CAN1
Bit 24 CRSRST: CRS reset (This bit is reserved for STM32L475xx/476xx/486xx devices)
Set and cleared by software.
0: No effect
1: Reset the CRS
Bit 23 I2C3RST: I2C3 reset
Set and reset by software.
0: No effect
1: Reset I2C3
Bit 22 I2C2RST: I2C2 reset
Set and cleared by software.
0: No effect
1: Reset I2C2
