MAINTENANCE & SUPPLIES, As Needed, RBC Transducer Cleaning Sequence
5-34 Sysmex SF-3000 Operator's Manual -- Revised September 1995
(3) Press [Clean RBC Transducer] key. The message "It will take approx. 2 min.
Press Start Switch" will be displayed.
Pressing [Cancel] cancels the program without cleaning and returns to the Service
Sequence submenu display.
Sysmex
Ready
DP:1234567890123
Manual Mode Next No. 1234567890123
XM HC GP DP SU
Sampler
<Service Sequence>
< Clean RBC Transducer >
It will take approx. 2 min.
Press Start Switch.
Cancel
Maintenance
Return
Figure 5-7-8: Clean Transducer Execute Message Window
(4) Press the Start Switch. The reagent is discharged from the detector chamber.
Sysmex
Running
DP:1234567890123
Maintenance Next No. 1234567890123
XM HC GP DP SU
Sampler
Draining reagent in the RBC Transducer.
Please wait.
Maintenance
Clean
RBC Transducer
Return
Figure 5-7-9: Cleaning Transducer Message Window (1)
