MAINTENANCE & SUPPLIES, Replacements, Piercer (Auto Sampler)
Sysmex SF-3000 Operator's Manual -- Revised September 1995
5
-57
(7)
Reset the CP cover.
CAUTION:
Take care not to pinch or bend the tubing when replacing the CP
cover.
(8)
Turn the power ON.
(9)
Reset the piercer counter by referring to
Section 9
in this chapter.
NOTE:
Make sure to reset the counter. If not reset, the message "Replace
Piercer" will remain on the LCD.
(10)
Record the replacement on the maintenance log.
