TROUBLESHOOTING
Sysmex SF-3000 Operator's Manual -- Revised September 1995 8-63
3.3 Test Motor
Following 4 programs are provided for the motor operation test.
• WB Asp Motor • Sheath Motor
• Rinse Motor • Mixing Motor
1 . WB Asp (Whole Blood Aspiration) Motor
This program performs test operation of the Whole Blood Aspiration Motor and positions
the motor in the correct initial position.
Run this test if a "WB Asp Motor Function Error" occurs and analysis cannot be
performed. If the test corrects the error, analysis will be possible after the system enters
the Ready mode.
(1) Bring the Test screen by pressing [Mainte.] and then [Test] keypads.
(2) Press the [WB Motor] keypad from the Test screen. The message "Press Start
Switch" will appear.
(3) Press the Start Switch. WB Aspiration Motor operation will begin. The WB
Aspiration Pump moves as shown in figure below.
During test operation, the message "Executing WB Motor test. Please wait." is
displayed.
①
➁
➂
Upper End
Lower End
Initial Position
Figure 8-9: WB Aspiration Pump Operation
NOTE: Only when it is required by Sysmex service representative, open the
Main Unit front panel behind the Sampler Unit (if installed), and
observe the operation of Whole Blood Aspiration Pump with his/her
assistance.
CAUTION: DO NOT open the front panel or try to remove the Sampler Unit
without instruction and assistance of Sysmex service representative.
