SYSMEX SF-3000 User Manual

TROUBLESHOOTING
Sysmex SF-3000 Operator's Manual -- Revised September 1995 8-67
3 . Rinse Mechanism Motor
This program performs test operation of the Manual Rinse Mechanism Motor and
positions the mechanism in the correct initial position.
Run this test if an "Rinse Motor Function Error" occurs and analysis cannot be
performed. If the test corrects the error, analysis will be possible after the system enters
the Ready mode.
(1) Bring the Test screen by pressing [Mainte.] and then [Test] keypads (Refer to
Section 3.1 in this chapter).
(2) Press the [Rinse Motor] keypad from the Test screen. The message "Press Start
Switch" will appear.
(3) Press the Start Switch. Rinse Mechanism motor operation will begin. Check
motor operation by observing Manual Rinse Mechanism as displayed in figure
below.
During test operation, the message "Executing Rinse Motor test. Please wait." is
displayed.
Initial Position
Lower End
Figure 8-11: Manual Rinse Mechanism Operation
(4) When operation ends, the message disappears. The mechanism will return to the
initial position.
(5) Press [Return] to end the test program.
The system automatically performs auto rinse to clean the hydraulic lines.
