SUPPLEMENT S2
Chapter 11 – Marking and Placards
CHAPTER 11 – MARKING AND PLACARDS
FLAP CONTROL
The flap switch selector is located on the instrument panel. It provides alternatively flap
control to either knob on the instrument panel (Std. mode) or hand control knob (Hand Control
mode). The following placard is positioned just above of it.
FIGURE 11-1, FLAP SELECTOR PLACARD
The flap control switch is located on the upper side of the hand control. The following placard
is just next to it.
