Tecnam P2002 JF - Brake Assembly Installation

Page 222 2
nd
Edition – Rev 0
32-10
MLG and BRAKES – MAINTENANCE PRACTICES
11. BRAKE ASSEMBLY INSTALLATION
Procedure
Step no.
Brake assembly installation
Task description
Additional info &
References
CAUTION
Refer to CMM Parker Cleveland P/N AWBCMM0001-7 last issue for more details about brake
assembly inspection/maintenance instructions
1.
If torque plate (1) was removed, install it in
the same rotational orientation as when
removed. Install torque plate on axle flange
(3) with attachment bolts, nuts, and washers
which hold the leg (2), the axle (3) and the
torque plate (1) together
Tighten the nuts as per standard torque value
(see Chapter 20-10)
Refer to Figure 14A/B.
2.
If wheel has been removed, install wheel prior
to installing brake cylinder assembly.
See instructions within
this Chapter
3.
Remove brake assembly back plate tie bolts
(1) and washers (2)
Refer to Figure 13.
4.
Install cylinder (3) in torque plate by sliding
(do not force) anchor bolts into torque plate
bushings.
Refer to Figure 13.
A dry film lubricant
should be applied to
anchor bolts and torque
plate bushings to provide
ease of installation and
operation. A liquid type
lubricant should not be
used as it will attract dirt
and moisture.
5.
Fit brake back plate: fit bolts (1) and washers
(2). Tighten bolts at torque value of 8.5-9 Nm
(75-80 In-lb). Restore slippage marks.
Refer to Figure 13.
Overtorquing could cause
depressions in the brake
cylinder, which result
in dragging or bound up
brakes. Refer also to
CMM Parker Cleveland
P/N AWBCMM0001-7
last issue.
