Tecnam P2002 JF - Hot Air Valves Replacement

Page 202 2
nd
Edition – Rev 0
21-10
CABIN HEATING – MAINTENANCE PRACTICE
3. HOT AIR VALVES REPLACEMENT
The following procedure applies to both LH and RH defrost valves.
Step
no.
Task description
Additional info &
References
1
Remove upper and lower engine cowling
2
Unscrew cabin heat valve control cable and remove
Bowden (and sheat) from Bowden stop on valve
Refer to Figure 11
3
Remove hot conduit from valve
Refer to Figure 14
4
Unscrew the bolt that attach valve to firewall
Refer to Figure 15
5
Remove hot valve
6
Reverse these step to install a new one, then apply hot
cabin heat rigging procedure
Figure 7 - Hot air valve
Figure 8 - Hot air valve fixing bolts
