Tecnam P2002 JF - Aileron Removal; Wing-Aileron Attachments

Page 208 2
nd
Edition - Rev 0
57-10
WINGS – MAINTENANCE PRACTICE
5. AILERON REMOVAL
Procedure
Step no.
Task description
Additional info &
References
1.
Disconnect the aileron control rod by
removing nut, washer and bolt
Refer to Figure 7.
2.
Loosen the mass balance
3.
Support the aileron and disconnect the
inboard and outboard aileron hinges by
removing nuts, washers and hinge bolts
Figure 7. – Wing-aileron attachments
