Tecnam P2002 JF - Main Wheel Removal

Page 210 2
nd
Edition – Rev 0
32-10
MLG and BRAKES – MAINTENANCE PRACTICES
4. MAIN WHEEL REMOVAL
Tools
Item
Quantity
Part Number / Notes
Main gear axle ring nut
wrench
1
Commercial
Procedure
Step
no.
Task description
Additional info &
References
1.
Make sure Master Switches are turned OFF.
2.
Lift aircraft on the jacks
Refer to Chapter 07-00
WARNING
INSURE AIRCRAFT IS SECURE AND STABLE BEFORE BEGINNING ANY WORK. WORKING
UNDER AN IMPROPERLY STABILIZED AIRCRAFT COULD CAUSE INJURY OR DEATH.
3.
Release parking brake
4.
Remove the fairing.
Refer to Figure 8.
5.
Remove brake assembly back plate tie bolts (1)
and washers, and remove back plate
Refer to Figure 9.
6.
Remove bolt (3) and nut (4). Remove wheel
axle ring (1) and axle ring nut (2)
Refer to Figure 10.
Refer to Figure 11.
7.
Pull wheel assembly off the axle
