Tecnam P2002 JF - Control Column Removal;Installation

Page 205 2
nd
Edition – Rev 0
27-20
AILERONS – MAINTENANCE PRACTICES
4. CONTROL COLUMN REMOVAL/INSTALLATION
Step
Task description
Additional info & References
1.
Remove seat(s)
See Chapter 12.41
2.
Unscrew and remove floor panel under seats
Refer to Figure 7.
3.
Remove control axis
Refer to tab. 03
4.
Unscrew upper link (lh/rh) item (A)
Refer to Figures 9. and 10.
5.
Unscrew lower link (lh/rh) item (B) (remove
coppiglia)
Refer to Figures 9. and 10.
6.
Unscrew and remove the aileron command cable
(lh/rh) item (C)
Refer to Figure 11.
7.
Unscrew and remove stabilator rod attachments
item (D)
Refer to Figure 12.
8.
Unscrew and remove control column/cabin-truss
attachments (lh/rh) item (E)
Refer to Figure 13.
9.
Pull out control column and replace (if necessary)
10.
Reinstall control column reversing these steps.
Torque according the torque value. All secure
wiring (if presents) need to be reinstall
See Chapter 20 Torque values
and Securing
Perform the final inspection
