Page 201 2
nd
Edition – Rev 0
12-20
OIL SYSTEM – SERVICING PRACTICES
Oil Level Checking and Filling Procedure
1. Open Engine cowling to access to oil tank (refer to Figure 2.)
2. Remove the filler cap; remove and clean the dipstick
3. Turn the propeller several times by hand in the direction of engine rotation to pump all
the oil from the engine to the oil tank (the process is complete when air flows back to
the oil tank, perceived by a gurgling)
4. Soak the dipstick in the oil tank
5. Read the oil level (refer to Figure 2): the level must be between the two marks
6. If necessary, replenish oil
At the selection of suitable lubricants refer to the additional
information provided by Rotax Operators Manual P/N 899371 -
last issue
7. Fit dipstick and filler cap
8. Clean up any spilled oil
9. Close oil tank and engine cowling
Figure 2. – Oil tank max and min marking
