Page 201 2
nd
Edition – Rev 0
12-40
SEATS – HANDLING AND CLEANING INSTRUCTIONS
Seats Removal and Installation Procedure
Procedure
1. Remove seats locking device (unscrew and remove, refer to Figure 9.)
2. Pull seat lever then slide seat all forward (refer to Figure 10.)
3. Pull Up seat and remove it from his location
4. Apply procedure for both seats
5. To reinstall seats, reverse these steps
Figure 9. – Seats locking device
Figure 10. – Seats remove procedure
