Tecnam P2002 JF - Fuel Pressure Indicator Replacement

Page 209 2
nd
Edition – Rev 0
28-10
FUEL SYSTEM – MAINTENANCE PRACTICE
6. FUEL PRESSURE INDICATOR REPLACEMENT
Step
Task description
Additional note
1.
Remove the instruments panel upper cover
2.
Remove Fuel press. indicator connectors
3.
Unscrew the attaching screws which fix the instrument to the
aluminum panel
Hold firmly the
instrument by hand
during removal
4.
Clear the instrument of the instrument panel
5.
Place into position the new/overhauled unit in correspondence
of the instrument panel cut-out
6.
Install the attaching screws which fix the instrument to the
aluminum panel
Hold firmly the
instrument by hand
during installation.
Do not over tighten
screws to avoid
instrument case
damage
7.
Install Fuel press. indicator connectors
8.
Perform a fuel pump test
Refer to Par. 02
