Tecnam P2002 JF - Canopy Removal;Installation Procedure

Page 201 2
nd
Edition – Rev 0
52-20
CANOPY REMOVAL / INSTALLATION – MAINTENANCE PRACTICES
1. CANOPY REMOVAL / INSTALLATION PROCEDURE
Procedure
Step
no.
Task description
Additional info
&
References
1.
Remove the locking pins from LH and RH Emergency Locks
Refer to Fig.14
2.
Push the LH and RH Emergency Locks out of the housing
Refer to Fig.15
3.
Remove the screws
Refer to Fig.16
4.
Loosen the nut behind the canopy key lock
Refer to Fig.17
5.
Extract the canopy from the guide rail, lifting up the canopy
Refer to Fig.18
6.
To install the canopy, reverse mentioned steps described in this table
7.
Make sure that the emergency locks are in place and the canopy
slides without binding after the installation procedure
