Tecnam P2002 JF - Main Wheel Installation

Page 212 2
nd
Edition – Rev 0
32-10
MLG and BRAKES – MAINTENANCE PRACTICES
5. MAIN WHEEL INSTALLATION
Tools
Item
Quantity
Part Number / Notes
Main gear axle ring nut
wrench
1
Commercial
Procedure
Step no.
Task description
Additional info &
References
1.
Make sure Master Switches are turned OFF.
WARNING
INSURE AIRCRAFT IS SECURE AND STABLE BEFORE BEGINNING ANY WORK. WORKING
UNDER AN IMPROPERLY STABILIZED AIRCRAFT COULD CAUSE INJURY OR DEATH.
2.
Make sure parking brake is released
3.
Install the wheel on the axle
4.
Fit wheel axle ring (1) and axle ring nut
(2).Tighten the ring nut, loosen and then
tighten it once again: make sure wheel can be
turned by hand with a slight friction and
without noise. Apply slippage mark. Fit bolt
(3) and nut (4).
Refer to Figure 10.
Refer to Figure 11A / B.
5.
Fit brake back plate: fit bolts (1) and washers .
Tighten bolts at torque value of 8.5 - 9 Nm
(75-80 In-lb).
Refer to Figure 9.
Overtorquing could cause
depressions in the brake
cylinder, which result
in dragging or bound up
brakes. Refer also to CMM
Parker Cleveland P/N
AWBCMM0001-7 last issue.
6.
Install the fairing
Refer to Figure 8.
