Page 203 2
nd
Edition – Rev 0
31-10
INDICATING SYSTEM –MAINTENACE PRACTICES
2. CLAMPED INDICATORS REPLACEMENT
The following procedure applies to those indicators fixed to the instrument panel by means of
stirrups, screwed themselves to the rear of the indicator. See figures below for reference:
Figure 8. – Example of clamped indicators
Figure 9. Example of clamped indicator – rear view
