Page 1 2
nd
Edition - Rev 0
71-40
ENGINE DRAINAGE – DESCRIPTION AND OPERATION
71-40 ENGINE DRAINAGE
DESCRIPTION AND OPERATION
Engine drainage system provides three different drainage lines (one per carbure-
tor). Carburetor drainage line gathers fuel leakages in a drip tray; then fuel is con-
veyed within hoses which, passing through firewall, ejects the overflow external-
ly.
Figure 11. - Engine drainage
