52-20
CANOPY REMOVAL / INSTALLATION – MAINTENANCE PRACTICES
2. BEARING TRACK REMOVAL / INSTALLATION PROCEDURE
Procedure
Step
no.
Task description
Additional info
&
References
1.
Remove the screws from the travel stop
Refer to Fig.19
2.
Remove the guide rail, moving it backward
Refer to Fig.20
3.
In order to remove the bearing track, unscrew the allen screws and
bolts
Refer to Fig.21
4.
Replace the bearings, bolts and self-locking nuts
Refer to Fig.22
5.
To install the guide rail on the fuselage, reverse mentioned steps
6.
Make sure that there is not play between bearings and guide rail
