Page 1 2
nd
Edition – Rev 0
32-20
BRAKE SYSTEM – DESCRIPTION AND OPERATION
32-20 BRAKE SYSTEM
DESCRIPTION AND OPERATION
The P2002JF can support two types of brake system to chosen by the customer:
Lever Brake System
Toe Brake System
LEVER BRAKE SYSTEM
The brake system consists of a brake fluid reservoir (1), a master cylinder (2) and two disc
brakes assemblies (3); an intercept valve activates parking brake (4). Braking action is through a
lever (5) located on cabin tunnel between seats. The brake system is equipped with a non-return
valve (6), which insures that braking action is always effective even if parking brake circuit
should accidentally be closed.
