Tecnam P2002 JF - Flap Actuator Replacement

Page 201 2
nd
Edition – Rev 0
27-30
FLAPS – MAINTENANCE PRACTICE
1. FLAP ACTUATOR REPLACEMENT
Step
Task description
Additional info & References
1.
Engage parking brake
2.
Make sure Master Switch is turned OFF. Pull out
flap motor breaker.
3.
Open (15) inspection cap
See Chapter 06
4.
Remove fasteners and disconnect flap actuator
connector.
Refer to Figures 16. and 17.
5.
Disconnect flap actuator from flap torque tube lever
and from FWD attachment: unscrew bolt.
Refer to Figures 15., 16. and 17.
6.
Remove actuator and replace if needed.
7.
Join FWD flap actuator attachment and flap
actuator rod end to flap torque tube lever
Refer to Figures 15., 16. and 17.
8.
Connect actuator connector and apply fasteners.
Refer to Figure. 17
9.
Close C4 inspection cap.
10.
Insert flap motor breaker and set Master Switch
ON.
11.
Check flap position
Refer to Chapter 57: Wing flap
installation
12.
Perform an operational control
