Page 3 2
nd
Edition – Rev 0
O6-00
DIMENSIONS AND AREAS
Cabin dimensions
Figure 1: Cabin dimensions
Control Surfaces Travel Limits
Ailerons
Up 20° 2°; down 15° 2°
Stabilator
Up 3° 1°; down 15° 1°
Trim
Up 2° 1°; down 9° 1°
Rudder
LH 30° 2°; RH 30° 2°
Flap
Up 0° 1°; T/O 15° 1°; FULL 40° 2°
