Tecnam P2002 JF - Stabilator Trim Tab Adjustment

Page 206 2
nd
Edition – Rev 0
27-50
RUDDER – DESCRIPTION AND OPERATION
3. STABILATOR TRIM TAB ADJUSTMENT
The following procedure table lists the operation to be carried out to adjust the trim tab
excursion:
Step
Task description
Additional info &
References
1.
Set the stabilator in its “zero” position and lock it in this
position
2.
Turn the Master switch ON
3.
Trim to maximum pitch-up
4.
Adjust thread of hinged control rod until tab is deflected
downwards 9° (use a protractor or measure downward
displacement of trailing edge – 9° is approximately
16mm
5.
Tighten lock-nut for adjustment thread and fasten
connecting pin of control rod to trim-tab
