Tecnam P2002 JF - Exhaust Spring

Page 203 2
nd
Edition – Rev 0
78-10
EXHAUST – MAINTENACE PRACTICES
Installation Procedure
Step
no.
Task description
Additional info &
References
1.
Engage parking brake
2.
Screw nut to connect exhaust manifold. Apply a
torque value of 12-20 N*m as suggest by
ROTAX 912S Installation Manual
Refer to Figure 3.
3.
Apply copper lubricant between exhaust
manifold and muffler
Refer to Figures 3B. and 3C.
4.
Install spring on exhaust manifold
Refer to Figure 3C.
5.
Apply sealant into the springs
Figure 2A, Sista SL509
High Heat Acetic Silicon or
equivalent
6.
Apply air system hoses on heat exchanger and
tighten screwing serflex
Refer to Figure 4.
7.
Install engine upper and lower cowling
See chapter 54
Figure 2A. Exhaust spring
