Tecnam P2002 JF - Flaps Removal; Wing-Flap Attachments and Mass Balance

Page 206 2
nd
Edition - Rev 0
57-10
WINGS – MAINTENANCE PRACTICE
3. FLAPS REMOVAL
Procedure
Step no.
Task description
Additional info &
References
1.
Fully extend the flaps and remove bolt,
washer and nut from the control rod end
Refer to Figure 6
2.
Support the Flap and disconnect the flap
hinges by removing nuts, washer and
hinge bolts;
3.
Pull the flap straight back off the wing
Figure 6. – Wing-flap attachments and mass balance
