Tecnam P2002 JF - Electric Fuel Pump Replacement

Page 206 2
nd
Edition – Rev 0
28-10
FUEL SYSTEM – MAINTENANCE PRACTICE
4. ELECTRIC FUEL PUMP REPLACEMENT
Step
Task description
Additional note
1.
Engage parking brake
2.
Set Master Switch OFF. Pull out fuel pump breakers.
3.
Open engine cowling
4.
Unscrew electrical fuel pump support
Refer to Figure 10.
5.
Remove electrical connection (single splice):
- Crop the two plastic serflex
- Remove the fireproof shield
- Disconnect splice
Refer to Figure 11.
6.
Remove the electrical fuel pump and replace (if necessary)
7.
Reverse these steps for electrical fuel pump installation
8.
Perform a fuel pump test for check proper fuel pump
operation
Refer to par. 02
