57-10
WINGS – MAINTENANCE PRACTICE
1. WING REMOVAL
Hereinafter they are addressed instruction to remove the wing assembly.
Procedure
Step
no.
Task description
Additional info &
References
1.
Set the Master Switch OFF and ground the air-
craft
2.
Drain both fuel tanks from drain valve of the
fuel tank and from the drain valve of gascola-
tor
Refer to Chapter 12 of this
manual
3.
Close the opposite side tank fuel circuit
4.
Remove the wing’s composite leading edge
5.
Remove all wing-fuselage fairings
6.
Remove the fuel tank outlet inspection panel,
Unfasten and remove the fuel hose from the
tank’s outlet. Place temporary a cap on line to
prevent spillage. Only for the left wing, dis-
connect also the fuel return line
7.
For the right wing, disconnect stall-warning
system wires
8.
Disconnect the fuel quantity sensor wiring and
the position lights wiring
9.
Disconnect flap control by removing roller
bearings that link push-pull rod
Refer to Figure 3.
10.
Empty the luggage compartment floor to get
the access to the aileron control circuit
11.
Disconnect aileron control by removing pins
that connect the small bar to the pushrods
Refer to Figure 4.
