Tecnam P2002 JF - Page 769

Page 202 2
nd
Edition - Rev 0
57-10
WINGS – MAINTENANCE PRACTICE
Step
no.
Task description
Additional info &
References
12.
Remove wing-fuselage pins
Refer to Figure 5.
13.
While supporting the wing, release at first the
rear spar pin and then the two main spar’s pins
14.
Provide to replace pins and cap fuel lines in
their original location.
Figure 3. – Flaps
