33-20
EXTERNAL LIGHTS MAINTENANCE PRACTICE
1. TAXI AND LANDING LIGHT REPLACEMENT
Step
no.
Task description
Additional info &
References
1.
Make sure Master Switches are turned off
2.
Open inspection cap
3.
Unfasten the lamp assy electrical terminals
4.
Remove lamp assy: remove the four adjusting screw
and springs and related washers supporting the assy
5.
Remove the four rivets which hold the flangea
together
6.
Separate the lamp unit from the flanges
7.
Set up again the lamp assy as removed: place the new
lamp unit between the FWD and AFT flange and
install the rivets
8.
Insert adjusting screws, washers and springs in the
lamp assy and put it in position. Screw fittings.
9.
Fasten electrical terminals
10.
Adjust map assy. Adjusting screws and springs allow
for orientating the light path as required
11.
Close inspection cap
2. WINGTIP NAV AND STROBE LIGHTS ASSY REPLACEMENT
Step
no.
Task description
Additional info &
References
1.
Make sure Master Switches are turned off
Ref. Figure 11.
2.
Unscrew the retaining screw (11). Remove retainer
(10) and lenses (9 and 6) with the gasket (5)
Ref. Figure 11.
3.
Remove the three screws which fix the base
plate to the wingtip. Record bonding cable position
Bonding cable is placed between the
wingtip and the base plate and it
engages a base plate fixing screw.
4.
Remove the base plate (1) disengaging both
electrical connectors
Ref. Figure 11.
5.
Replace flashtube assy (8) as required
Ref. Figure 11.
6.
Engage both electrical connectors and place in
position the bonding cable
7.
Install the base plate (1), insert the three screws
into the base plate holes and tighten firmly.
Ref. Figure 11.
8.
Place in position lenses (9 and 6) with the gasket (5)
Ref. Figure 11.
9.
Put in position the retainer (10) and fasten the
retaining screw (11).
Ref. Figure 11.
