STARTING – DESCRIPTION AND OPERATION
80-10 STARTING
DESCRIPTION AND OPERATION
Rotax engine features an electric starter and a relay located in the engine, con-
nected to the firewall.
The starter button is activated by the key.
The key rotation energizes the starter relay, closing the relay contacts to connect
the external power supply or aircraft battery to the connection of the starter.
Figure 1. – Starting system
The wiring diagram is reported on Chapter 92.
