Page 206 2
nd
Edition – Rev 0
23 – 10
COMM 1 and 2 – MANTEINANCE PRACTICE
Turn (clockwise) and carefully hand-tighten (4
in-lb max.) the cam lock mechanism using only
the 3/32" hex driver
Using a larger tool than the one
prescribed makes it easy to exceed
the allowable torque on the cam
lock resulting in damage to the
unit. The unit will be pulled into
the frame securing the unit and
the connectors.
Do NOT overtighten. The back of
the bezel must be flush to the
mounting tube. If the cam lock is
hard to turn or the unit does not
seat fully, the unit is probably
binding and the mounting tube
should be checked.
See CMM post installation check-
out
6. SL30 / SL 40 periodic maintenance
The SL30 unit is designed to not require any regular general maintenance.
Cleaning the front panel
The front bezel, keypad, and display can be cleaned with a soft cotton cloth dampened with
clean water. DO NOT use any chemical cleaning agents. Care should be taken to avoid
scratching the surface of the display.
