SAFETY BELTS – DESCRIPTION AND OPERATION
25-20 SAFETY BELTS
DESCRIPTION AND OPERATION
Herein after is shown safety belt system for P2002 JF aircraft.
Each seat is fitted with a safety belt featuring four attaching points.
Figure 3. - Safety belts scheme
Figure 4. - Safety belt lower attachment
SAFETY BELT LOWER
ATTACHMENT (LH SHOWN
RH OPPOSITE)
SAFETY BELT LOWER
ATTACHMENT (CENTRAL)
