Tecnam P2002 JF - Hot Air Valves Control Cable Replacement

Page 204 2
nd
Edition – Rev 0
21-10
CABIN HEATING – MAINTENANCE PRACTICE
4. HOT AIR VALVES CONTROL CABLE REPLACEMENT
Step
no.
Task description
Additional info &
References
1
Remove upper and lower engine cowling
2
Unscrew cabin heat valve control cable
Refer to Figure 11.
3
Pull out cabin heat knob from its housing
Refer to Figure 12.
4
Unscrew cabin heat lever head
Refer to Figure 13.
5
Remove Bowden (if necessary) and replace
Refer to Figure 13.
6
Reinstall cabin heat control knob to its location
Refer to Figure 12.
7
Apply cabin heat control valve rigging procedure
