Tecnam P2002 JF - Propeller Removal

Page 201 2
nd
Edition – Rev 0
61-10
PROPELLER – MAINTENACE PRACTICES
1. PROPELLER REMOVAL
Procedure
Step
no.
Propeller removal
Task description
Additional info &
References
1.
Make sure Master Switch is turned OFF.
2.
Parking brake: engage
3.
Engine starter circuit breaker: pull out
4.
Remove engine upper cowling unscrewing
along the edges.
5.
Remove the spinner
Refer to Figure 2.
6.
Remove screws holding spinner dome to
spinner bulkhead
7.
Remove safeting
8.
Remove bolts that secure propeller to the
hub
Refer to Figure 3.
NOTE
REPLACE ALWAYS THE SELF LOCKING NUTS WITH NEW ONES
9.
Pull slowly propeller off from its position
NOTA: After removal, do not lay propeller down on its tip but always lay flat and away
from sources of humidity, heat or, in any case, away from areas subject to excessive
temperature change
