Tecnam P2002 JF - Nlg Damper On-Aircraft Maintenance

Page 205 2
nd
Edition – Rev 0
32-40
NOSE LANDING GEAR – MAINTENANCE PRACTICES
7. NLG DAMPER ON-AIRCRAFT MAINTENANCE
Procedure
Step
no.
NLG removal
Task description
Additional info &
References
1.
Make sure Master Switches are turned OFF.
WARNING
INSURE AIRCRAFT IS SECURE AND STABLE
BEFORE BEGINNING ANY WORK, WORKING
UNDER AN IMPROPERLY STABILIZDED
AIRCRAFT COULD CAUSE INJURY OR DEATH
2.
Remove nose gear fairings
3.
Lift the airplane on jacks until the wheels are clear of
the ground
Refer to Chapter 07-0,
Jacking Procedure
As alternative, engage
parking, chock main
wheels, press down the
stabilator front spar,
adjacent to the fuselage, to
raise the nose wheel; then
place the nose trestle in
correspondence of the first
fuselage bulkhead.
4.
Remove upper and lower pins
Refer to Figure 23.
5.
If play is not present, substitute rubbers
Refer to Figure 23.
6.
Reinstall upper and lower pins, perform a check of all
procedure.
