Tecnam P2002 JF - Engine Mount Attachment Points

Page 203 2
nd
Edition - Rev 0
71-20
ENGINE MOUNT – MAINTENANCE PROCESSES
Step
no.
Engine mount installation
Task description
Additional info &
References
5.
Lower attachments:
 Bolt: AN4-25 (2x)
 Washer:AN960-416 L (4x)
 Self-locking nut: MS21042-4 (2x)
Refer to Figure 4.
NOTE
REPLACE ALWAYS THE SELF LOCKING NUTS WITH NEW ONES
6.
Apply a torque value of 10 N*m
Figure 7. – Engine mount attachment points
