Tecnam P2002 JF - Hydraulic Differential Brake Circuit (Optional)

Page 11 2
nd
Edition – Rev 0
03-00
AIRPLANE GENERAL DESCRIPTION
The differential brake circuit as shown in the Figure 11 (Optional). Control lever (1) activates
pump (3) that features built-in brake fluid reservoir (4); check valve (5) secure brake function
when activated , unintentionally, parking brake.
Figure 11: Hydraulic differential brake circuit (Optional)
C
C
C
C
FWD
