Tecnam P2002 JF - Electric Fuel Pump Filter Cleaning; Gascolator

Page 212 2
nd
Edition – Rev 0
28-10
FUEL SYSTEM – MAINTENANCE PRACTICE
10. ELECTRIC FUEL PUMP FILTER CLEANING
Step
Task description
Additional note
1.
Make sure that Master Switch is turned OFF. Pull out fuel
pump breakers.
2.
Open engine cowling;
Refer to Chapter 06
3.
Place a container under the electric fuel pump, so to gather eventual
fuel leakages;
4.
Remove safety wire;
Refer to Figure 16.
5.
Unscrew wheel electric fuel pump lower cover;
Refer to Figure 16.
6.
Remove gasket, then filter;
7.
Clean filter by suitable means, removing all impurities;
8.
Place filter into the pump, then apply gasket;
9.
Screw electric fuel pump lower cover;
Refer to Figure 16.
10.
Fasten lower cover by safety wire;
Refer to Figure 16.
11.
Close engine cowling and perform a fuel pump test.
Refer to Par. 2
Figure 10. – Gascolator
