Tecnam P2002 JF - Seats Installation; Seats Removal

Page 201
SUPPLEMENT S2
SERVICING- POST-SHIPMENT REASSEMBLY INSTRUCTION
1
st
Edition - Rev
1. SEATS REMOVAL
Procedure
Step no.
Seats removal
Task description
Additional info &
References
1.
Engage parking brake
2.
Make sure that Master switch is set to OFF
3.
Remove seats locking device Refer to Figure 12.1.
4.
Pull seat lever, then slide seat all forward Refer to Figure 12.2.
5.
Pull up seat and remove it from his location
6.
Apply the same procedure for the other seat
2. SEATS INSTALLATION
Procedure
Step no.
Seats installation
Task description
Additional info &
References
1.
Engage parking brake
2.
Make sure that Master switch is set to off
3.
Put seat in his location
4.
Pull seat lever, then slide seat all backward
5.
Install seats locking device
