RUDDER – DESCRIPTION AND OPERATION
2. STABILATOR TRIM TAB ACTUATOR REPLACEMENT
Additional info &
References
Disconnect the trim actuator electrical wiring from the
trim actuator.
With reference to Figures 22. and 23. remove in order:
Tail cone fairing
Item (14) – cotter pin
Item (19) and (10) – pin and washer
Items (20) – bolts. Unscrewing bolts from actuator
support plate
Items (10) (11) – washers and nuts
Item (6) – actuator. Pull out actuator from it’s
housing
Refer to:
Figure 22.
Figure 23.
Figure 24.
Figure 25.
Figure 26.
Reinstall all actuator fitting and tail cone fairing
Refer to Figures 22., 23. and
26.
Connect the trim actuator electrical wiring to the trim
actuator
Test stabilator trim command acting it from the switch on
control stick. Check the trim tab travel limit
