Tecnam P2002 JF - Volt-Meter;Ammeter Replacement

Page 207 2
nd
Edition – Rev 0
24-10
POWER GENERATION – MAINTENANCE PRACTICE
6. VOLTMETER/AMMETER REPLACEMENT
Step no.
Volt-meter Amp-Meter replacement
Task description
Additional info &
References
1.
Remove the instruments panel upper cover
2.
Remove voltmeter (AmMeter) wires
3.
Unscrew the attaching screws which fix the
instrument to the aluminum panel
Hold firmly the instrument by
hand during removal
4.
Clear the voltmeter (AmMeter) of the instrument
panel
5.
Place into position the new/overhauled unit in
correspondence of the instrument panel cut-out
6.
Install the attaching screws which fix the ins volt-
ammeter to the aluminum panel
Hold firmly the instrument by
hand during installation. Do
not over tighten screws to
avoid instrument case
damage
7.
Install voltmeter (ammeter) wires
8.
Install the instruments panel upper cover
9.
Perform volt-meter (ammeter) functional test
