AIRPLANE GENERAL DESCRIPTION
General Features
Following tables provide general information about airplane and its systems. The dimensions
reported hereinafter are for reference only and are not for inspection purposes.
Wing
Wing span
8.6 m
Wing surface
11.5 m
2
Wing loading
50 kg/m
2
Aspect ratio
6.4
Taper ratio
0.6
Dihedral
5°
Fuselage
Length overall
6.61 m
Width overall
1.11 m
Height overall
2.43 m
Empennage
Stabilator span
2.90 m
Vertical tail span
1.10 m
Landing Gear
Wheel track
1.85 m
Wheel base
1.62 m
Main wheel tyres: Air Trac
5.00-5
Main Gear Wheel & Brakes: Cleveland
199-102
Nose gear tyre: Air Trac
5.00
Control surface travel
Ailerons
Up 20°  2°; down 15°  2°
Stabilator
Up 3°  1°; down 15°  1°
Trim tab
Up 2°  1°; down 9°  1°
Rudder
LH 30°  2°; RH 30°  2°
Flap
Up 0° 1°; T/O 15°  1°; FULL 40°  2°
