Page 200 2
nd
Edition – Rev 0
12-40
SEATS – HANDLING AND CLEANING INSTRUCTIONS
12-40 SEATS – Handling and cleaning instructions
General
The P2002 has two seats, each seat is horizontally adjustable..
They are mounted on two parallel tracks, attached to the compartment floor structure, which
allow the seat to move forward or rearward.
Each seat consists of the following main components:
(1) Primary Structure Assembly consisting of the sitting and backrest assemblies.
(2) Horizontal Position Adjustment System allowing for the horizontal position adjustment.
The device consists of a lever located in the lower side of the structure.
Figure 8. – Seats
