Tecnam P2002 JF - Engine Cowling Removal

Page 201 2
nd
Edition - Rev 0
71-10
ENGINE COWLINGS – DESCRIPTION AND OPERATION
1. ENGINE COWLING REMOVAL
Procedure
Step
no.
Engine cowling removal
Task description
Additional info &
References
1.
Engage parking brake
2.
Loosen the screws inside the engine cowling
Refer to Figure 2.
3.
Remove the upper cowling
4.
Remove the lateral pins of the lower cowling
and loosen the screws in the down side
Refer to Figure 3.
5.
Remove the lower cowling
Figure 2. – Upper engine cowling screws
